MULTI CHANNEL MINIATURE INSTRUMENT
The OEM-MC Mini’s compact size and low power make it the perfect solution for integrating with scanners, robots and automation systems.
Mounting the UT electronics on the scanner allows for shorter probe cables providing improvement in signal quality, where you then only need to run a 12V DC cable and Gigabit Ethernet cable back to the laptop.
There is even now a Power Over Ethernet (PoE) option.
KEY BENEFITS
- Low-cost, high-channel count and high-performance
- Multiplexed from 16 to 64 channels
- Daisy-chain several boards for more channels and higher productivity
- Small form factor
- Open platform: controlled via SoftwareAPI
Specifications
Configurations
16 Channels
32 Channels
64 Channels
Mode
Multiplexed
Available Configurations
Pulse/Echo
Pitch & Catch
Best Analog Performance
Pulse :
150V Negative Square
PRF :
20kHz (higher in option)
Receiver Resolution :
14bits
Receiver Gain Range :
100 dB
Bandwith :
50kHz to 20 MHz
Communication
LAN (TCP Protocol, Gigabit Ethernet)
Signal Processing
FIR Filter :
Up to 64 taps
AScan Resolution :
8,16 bits
AScan Sampling :
100MHz
Small form factor
Dimensions (L x W x H)
Min :
115 x 150 x 15 mm
4.53 x 5.09 x 0.59 in
Weight :
< 250g / 0.55 lb
Low Power
Voltage :
12V
Power :
10W* (see datasheet for more details)
Robust Software Development Kit (SDK)
Easy-to-use API Library. (C++, C#, LabVIEW, MATLAB, Python)
Linux Driver also available!
Applications
CORROSION MAPPING
SCANNERS AND CRAWLERS
Ultra-high-speed acquisition
SUBSEA APPLICATIONS
PLaTE INSPECTION
OPTIONS AVAILABLE
I/O Fiber
Optical Fiber > 100m
Double or Single Ended
PoE+
Power Over Ethernet
Daisy Chained
For multi electronic
or multi probe applications
